SAN Storage
VTrak D5000 Series
The D5000 family umbrella — shared controllers, upgrades, and ServicePlus coverage for every D5000 model.
Genuine VTrak D5000 Series hardware with full manufacturer warranty, configuration review on every order, and formal line-itemed quotes from our US-based team.
Order
VTrak D5000 Series Part Numbers
Controllers & Spares
4 part numbersReplacement controllers and controller-level service parts for dual-controller VTrak RAID subsystems
X50CTLX16
VTrak D5000x RAID Controller — 2 × 10G SFP+
- Component
- RAID controller (1-pack)
- Host Ports
- 2 × 10G SFP+
- For Platform
- VTrak D5000x
Single replacement D5000x controller with two 10G SFP+ Ethernet ports — the Ethernet/iSCSI counterpart to the FC-equipped D5000fx module.
X50CTLFX16
VTrak D5000fx RAID Controller — 10G SFP+ & 16G FC
- Component
- RAID controller (1-pack)
- Host Ports
- 2 × 10G SFP+ · 16G FC
- For Platform
- VTrak D5000fx
Single replacement D5000fx controller pairing two 10G SFP+ Ethernet ports with 16G Fibre Channel host ports for FC SAN deployments.
X50CTL16G
Spare Controller FRU with 2 × 4 GB — VTrak E5000F
- Component
- Controller FRU (2 × 4 GB)
- Host Ports
- —
- For Platform
- VTrak E5000F
Factory spare controller FRU with 2 × 4 GB memory for the Fibre Channel VTrak E5000F — keep on hand to restore dual-controller redundancy quickly.
X50CTLPSU1
Service Part Kit — VTrak E5600/E5800
- Component
- Service part kit
- Host Ports
- —
- For Platform
- VTrak E5600 / E5800
Factory service part kit for VTrak E5600/E5800 subsystems — a chassis field-replacement kit rather than a D5000 controller.
Spares & Accessories
7 part numbersField-replaceable spare modules for VTrak D5000-family and X5000 subsystems
X50DVSS3A4P4
4 TB HDD Drive Module 4-Pack — VTrak X5000
- Capacity / Rating
- 4 TB per drive (×4)
- Type
- HDD drive module
- For Platform
- VTrak X5000
- Pack
- 4-pack
Four 4 TB spare drive modules in one pack — the economical way to populate empty bays or add capacity in steps on a VTrak X5000.
X50DVSS3A8
8 TB HDD Drive Module — VTrak X5000
- Capacity / Rating
- 8 TB
- Type
- HDD drive module
- For Platform
- VTrak X5000
- Pack
- 1-pack
Single 8 TB spare drive module for VTrak X5000 — the mid-capacity option between the 4 TB pack and the 12/14 TB modules.
X50DVSS3A12
12 TB NL-SAS HDD Drive Module — VTrak X5000
- Capacity / Rating
- 12 TB
- Type
- 12G NL-SAS HDD drive module
- For Platform
- VTrak X5000
- Pack
- 1-pack
Single boxed 12 TB 12G NL-SAS drive module for VTrak X5000 — more capacity per bay than the 4 TB and 8 TB options.
X50DVSS3A14
14 TB HDD Drive Module — VTrak X5000
- Capacity / Rating
- 14 TB
- Type
- HDD drive module
- For Platform
- VTrak X5000
- Pack
- 1-pack
Highest-capacity drive module in this group at 14 TB per bay — maximizes usable capacity per slot in a VTrak X5000.
D5KDDR32G1P
32 GB DDR4 VLP Memory Module — VTrak D5000
- Capacity / Rating
- 32 GB
- Type
- DDR4 VLP memory module
- For Platform
- VTrak D5000
- Pack
- 1-pack
32 GB DDR4 VLP DIMM for expanding controller memory in a VTrak D5000 — the only cache/memory upgrade in this group.
X50PSU800
800 W Power Supply — VTrak D5000/E5000
- Capacity / Rating
- 800 W
- Type
- Power supply unit
- For Platform
- VTrak D5000 / E5000
- Pack
- 1-pack
Spare 800 W power supply that fits both VTrak D5000 and E5000 chassis — restores power redundancy after a PSU failure.
X50SFP10GBASET
10GBase-T SFP+ Transceiver — VTrak D5000
- Capacity / Rating
- 10 Gb
- Type
- 10GBase-T SFP+ transceiver
- For Platform
- VTrak D5000
- Pack
- 1-pack
10GBase-T SFP+ module for a VTrak D5000 controller port — runs 10 GbE over copper RJ-45 cabling instead of optics or DAC.
ServicePlus & Support
17 part numbersBase VTrak D5000 coverage is 3-year 24×7 support with next-business-day onsite parts — these SKUs extend the term, upgrade response time, or add drive disposal
VT5KEW2YHDAPAC
Extended Warranty — 2 Yr, With HDD (APAC)
- Service Type
- Extended warranty
- Term
- +2 yr
- Drive Coverage
- HDD
- Applies To
- VTrak D/E5000
Adds 2 years of coverage to a VTrak D/E5000 populated with HDDs; APAC-region SKU.
VT5KEX2YAPAC
Extended Warranty — 2 Yr, Without HDD (APAC)
- Service Type
- Extended warranty
- Term
- +2 yr
- Drive Coverage
- None (diskless)
- Applies To
- VTrak D/E5000
Adds 2 years of coverage to a diskless (no-HDD) VTrak D/E5000; APAC-region SKU.
VTDE5KX2YESSDX
Extended Warranty — 2 Yr, With SSD
$5,774.00
- Service Type
- Extended warranty
- Term
- +2 yr
- Drive Coverage
- SSD
- Applies To
- VTrak D/E5000
Adds 2 years of coverage to a VTrak D/E5000 configured with SSDs.
VTDE5KE1Y600TX
Extended Warranty — 6th Year, Without HDD
$1,087.95
- Service Type
- Extended warranty
- Term
- Year 6 (+1 yr)
- Drive Coverage
- None (diskless)
- Applies To
- VTrak D/E5000
Extends coverage through year 6 for a diskless VTrak D/E5000 after the initial five years.
VTDE5KE1Y6HDDX
Extended Warranty — 6th Year, With HDD
$2,735.06
- Service Type
- Extended warranty
- Term
- Year 6 (+1 yr)
- Drive Coverage
- HDD
- Applies To
- VTrak D/E5000
Extends coverage through year 6 for an HDD-populated VTrak D/E5000.
VTDE5KE1Y6SDDX
Extended Warranty — 6th Year, With SSD
- Service Type
- Extended warranty
- Term
- Year 6 (+1 yr)
- Drive Coverage
- SSD
- Applies To
- VTrak D/E5000
Extends coverage through year 6 for an SSD-configured VTrak D/E5000.
VTDE5KX1Y7SSDX
Extended Warranty — 7th Year, With SSD
- Service Type
- Extended warranty
- Term
- Year 7 (+1 yr)
- Drive Coverage
- SSD
- Applies To
- VTrak D/E5000
Extends SSD-system coverage into year 7 — the follow-on to the 6th-year SSD warranty SKU.
VTDE5KX1Y8SSDX
Extended Warranty — 8th–10th Year, With SSD
$15,194.75
- Service Type
- Extended warranty
- Term
- Years 8–10
- Drive Coverage
- SSD
- Applies To
- VTrak D/E5000
Late-life coverage for SSD-configured systems spanning years 8 through 10 — the longest extension in this group.
VT5KPSP2Y
ServicePlus PSP — 2 Yr, Next-Business-Day Onsite
- Service Type
- ServicePlus PSP, NBD onsite
- Term
- 2 yr
- Drive Coverage
- HDD or diskless
- Applies To
- VTrak X5000
2-year ServicePlus uptime plan with next-business-day onsite service for VTrak X5000, with or without HDDs installed.
VT5KPSP3Y
ServicePlus PSP — 3 Yr, Next-Business-Day Onsite
- Service Type
- ServicePlus PSP, NBD onsite
- Term
- 3 yr
- Drive Coverage
- —
- Applies To
- VTrak X5000
3-year ServicePlus uptime plan with next-business-day onsite service for VTrak X5000 — one year longer than the 2-year PSP.
R3YOS2
ServicePlus PSP — 3 Yr, 4-Hour Onsite Response
$1,969.24
- Service Type
- ServicePlus PSP, 4-hr onsite
- Term
- 3 yr
- Drive Coverage
- —
- Applies To
- VTrak X5000
Fastest response tier here: 3-year ServicePlus with 4-hour onsite response for VTrak X5000, for downtime-critical deployments.
KYHD2Y
HDD Disposal Service — 2 Yr
- Service Type
- Drive disposal
- Term
- 2 yr
- Drive Coverage
- HDD
- Applies To
- VTrak X5000
2-year plan covering disposal of replaced hard drives from a VTrak X5000.
KYHD3Y
HDD Disposal Service — 3 Yr
- Service Type
- Drive disposal
- Term
- 3 yr
- Drive Coverage
- HDD
- Applies To
- VTrak X5000
3-year plan covering disposal of replaced hard drives from a VTrak X5000.
KYSSSD2Y
SAS SSD Disposal Service — 2 Yr
$3,215.20
- Service Type
- Drive disposal
- Term
- 2 yr
- Drive Coverage
- SAS SSD
- Applies To
- VTrak X5000
2-year disposal plan for replaced SAS SSDs in a VTrak X5000.
KYSSSD3Y
SAS SSD Disposal Service — 3 Yr
$3,993.18
- Service Type
- Drive disposal
- Term
- 3 yr
- Drive Coverage
- SAS SSD
- Applies To
- VTrak X5000
3-year disposal plan for replaced SAS SSDs in a VTrak X5000.
KYSTSD2Y
SATA SSD Disposal Service — 2 Yr
$1,865.91
- Service Type
- Drive disposal
- Term
- 2 yr
- Drive Coverage
- SATA SSD
- Applies To
- VTrak X5000
2-year disposal plan for replaced SATA SSDs in a VTrak X5000.
KYSTSD3Y
SATA SSD Disposal Service — 3 Yr
$2,534.48
- Service Type
- Drive disposal
- Term
- 3 yr
- Drive Coverage
- SATA SSD
- Applies To
- VTrak X5000
3-year disposal plan for replaced SATA SSDs in a VTrak X5000.
Don't see the configuration you need? Request a quote — we can source the full Promise Technology catalog, including custom drive configurations.
